Wrapping

Wrapping is used to adjust tape lengths, widths, or core diameters – ideal for optimizing logistics and processing. Krückemeyer offers flexible wrapping options, including for delicate or composite materials.

Manufacturing capabilities Send inquiry

Verfahren mit Umwickeln

Technique<\/strong><\/td>	Winding the base materials onto different cores (hubs)<\/td><\/tr>
Core sizes<\/strong><\/td>

Materialkombinationen	Multiple layers of identical or different materials
Klebstoffkombinationen	Self-adhesive outfitting, single- and double-sided
Verbundmaterialien	All cuttable and wrapable materials

With our winding technology, we can laminate materials by means of adhesive techniques and deliberately combine their properties.

Technique	Cold coating - outfitting materials with transfer films
Advantage	Individual adjustment of adhesive properties

We apply a self-adhesive backing to non-adhesive materials using a wrap-around technique – depending on the requirement, single-sided or double-sided.

Technique<\/strong><\/td>	Outfitting non-adhesive areas on the adhesive surface<\/td><\/tr>
Versions<\/strong><\/td>	Strip tapes in custom dimensions<\/td><\/tr>
Specials<\/strong><\/td>

Technique	Replacement of the liner protective cover
Manufacturing advantage	Improved processing (punching & cutting)
Application advantage	Better protection for the application
Materials	Custom film types
Feature	Optional printing

For double-sided adhesive materials, we replace the liner protective cover by wrapping: the existing liner is peeled off and replaced with a new protective cover.

Tape widths	2-9 mm
Tape lengths	up to approx. 30,000 m
Reel diameter	up to 500 mm
Reel width	up to 500 mm
Hub diameter	30 mm / 3" / 6"

Individual materials can also be criss-cross wound as narrow tapes on cross-wound spools — with very long run lengths available on request.

Cut widths<\/strong><\/td>	up to 1,600 mm<\/span><\/td><\/tr>
Cut lengths<\/strong><\/td>	up to 1,500 m<\/td><\/tr>

Single-sided adhesive tapes<\/strong><\/td>	Film \| Fabric \| Foam \| Paper<\/td><\/tr>
Double-sided adhesive tapes<\/strong><\/td>	Acrylate foam \| Foam \| Film \| Nonwoven \| Fabric \| Transfer films<\/td><\/tr>
Technical films<\/strong><\/td>	PE \| PP \| PTFE \| PI \| PVC \| and more<\/td><\/tr>
Foams<\/strong><\/td>	PE \| PU \| EPDM<\/td><\/tr>
Transfer films<\/strong><\/td>

Raw materials	Jumbo- & Logware
Roll goods	Custom running lengths & core sizes
Self-adhesive outfitting	Custom transfer adhesive films
Lamination	Custom material combinations & layers

With our winding techniques we realize customized configurations in different dimensions – precisely tailored to your application and your process.

Umwickeln im Überblick

During rewinding of film and adhesive tape materials, roll goods are carefully wound or rewound. In converting, this primarily means precise winding with consistently controlled web tension to achieve defined run lengths, roll widths, and core diameters, and to minimize typical web defects such as creases. In industry, rewinding is often directly combined with cutting and cutting to length (see cut spools) – which noticeably speeds up processing, both manually and automatically.
