Tape cutting

Tape cutting enables millimeter-precise rolls or strip cuts for ready-to-install applications. Krückemeyer cuts tapes exactly to customer specifications – even with tight tolerances and special formats.

Manufacturing capabilities Send inquiry

Klebeband schneiden individuell

Cutting widths	3 mm to 1,600 mm (material dependent)
Tolerances	approx. 0.5 mm (material dependent)

Almost every tape type can be supplied as roll stock exactly in the width you need—from ultra-thin to very large. The key factor is always the combination of material and core: It determines which widths are ultimately possible.

Wrapping + Cutting	approx. 1 to 1,500 m
Cut reels	up to 1,500 m
Cross-wound reels	up to 30,000 m

Even beyond the usual standard sizes, you can get exactly the roll length that fits your workflow. And if you need different cores: we wind the material to the desired length onto the respective cores – in the way that is easiest for you to process.

Saw widths<\/strong><\/td>

Fine roll cuts

from 0.5 mm (material-dependent)

Depending on the material, we can also cut tapes in very narrow widths.

Slit widths	up to 1,600 mm
Cut lengths	up to 1,500 m
Core diameter	3" \| 6" \| 30 mm

With slitting reels, adhesive tape and film rolls are wound in a single step, brought to the desired length, and cut—producing reels that are exactly in the dimensions you require.

Tape widths	2-9 mm
Tape lengths	up to approx. 30,000 m
Spool diameter	up to 500 mm
Spool width	up to 500 mm
Core diameter	30 mm / 3"/ 6"

Single-sided tapes	Film \| Fabric \| Foam \| Paper
Double-sided tapes	Acrylate foam \| Foam \| Film \| Nonwoven \| Fabric \| Transfer films
Technical films	PE \| PP \| PTFE \| PI \| PVC \| and more
Foams	PE \| PU \| EPDM

Beyond the materials mentioned above, essentially any material that can be cut to size and wound can be processed.

Rollenware<\/strong><\/td>	Roll stock in standard sizes + more<\/td><\/tr>
Bogenware<\/strong><\/td>	Custom cuts<\/td><\/tr>
Kreuzspulen<\/strong><\/td>	Long tapes up to 30,000 m in length<\/td><\/tr>
Maschinenklebeband<\/strong><\/td>

Häufige Fragen zum Klebeband schneiden

During adhesive tape cutting, wide jumbo rolls or slitter lines are precisely cut to the customer's desired widths. The goal is to tailor the tape exactly to the component geometry, the application process and handling.

The method is particularly advantageous when:

special widths of commercially available products are required
production processes should be optimized
manual cuts as pre- or post-processing should be eliminated
automated applications are supported
to optimize material utilization

Individually cut rolls increase efficiency, process reliability and assembly speed.

As a rule, nearly all commercially available roll goods can be processed, including:

Single- and double-sided adhesive tapes
Transfer tapes
Foam adhesive tapes
Technical films
Protective and functional films
Multilayer laminate composites

Material combinations, rewound core diameters (e.g., 1 in, 1.5 in, 3 in or 6 in) as well as special length requirements are feasible.

The costs depend, among other things, on:

Material type and material thickness
Desired cutting width
Number of cuts per roll
Roll length
Core diameter
Quantity or call-off quantity
Additional services such as rewinding or special packaging

The higher the quantity and the more efficient the material utilization, the more cost-effective the solution.

The minimum quantity depends on the material used and the desired cut width.

Typically, production is based on master rolls or jumbo rolls. Smaller runs or project-related quantities are also possible – depending on material usage and economic feasibility.

For a quick and accurate calculation, the following details are helpful:

Material designation or desired properties
Desired roll width
Roll length
Core diameter
Quantity or annual requirement
Details about the application process (manual or automated)

The more detailed the information, the more accurately we can develop the optimal solution.

Yes, cut-to-size samples are available.

This allows testing of widths, handling, and application prior to production release. Samples support development projects, process validations, and production ramp-ups.
